Votronic Tank sensor FLTank sensor for plastic or metal tanks.
The tank sensors measure the level in the tank and transmit the measured value with only 2 lines to the display unit. They are powered by 12V or 24V from the display unit and are powerless when idle. The moulded electronics (IP 67) is also suitable for inhospitable operation on underfloor tanks and frost-proof. All VOTRONIC tank sensors work independently of pressure, i.e. there is no measurement value distortion in case of excess pressure in the tank, pressure refueling etc. Also included is the standard protection against reverse polarity, overvoltage, short circuit and overload.
Product details: - Flexible rope probe, easy to shorten to tank height.
- Only suitable for tanks with cleaning opening.
- For plastic tanks: wall thickness max. 8 mm.
- Connection via screw terminals.
Technical data: Tank sensor FLOperating voltage 12 V and 24 V. Mounting on the tank top/side wall. Tank height 30 - 100 cm. Box contents: flexible rope probe, tank wall passage, stainless steel arrester, mounting screws, instruction manual (English language not guaranteed). Download
