Model :ELP-USBFHD06H serial
 Sensor:IMX322/IMX323
 Lens Size:1/2.9 inch
 Pixel Size:12.8X11.6 mm
 Image area:2000(H)X1121(V) approx. 2.24 M pixels
 Max. Resolution 1080P
 Compression format
H264 /MJPEG / YUV2(YUYV) Resolution & frame
 H264:320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps/800X600@ 30fps/1280X720@ 30fps/1920X1080@ 30fps
 MJPEG:320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 30fps/1280X720@ 30fps/1920X1080@ 30fps
 YUV:320X240@ 30fps /352X288@ 30fps /640X360@ 30fps /640X480@ 30fps /800X600@ 15 fps
 S/N Ratio:42dB
 Dynamic Range:86dB
 Sensitivity:5.0V/lux-sec@550nm
 Mini illumination:0. 01 lux
 Shutter Type:Electronic rolling shutter / Frame exposure
 Connecting Port type:USB2.0 High Speed
 Free Drive Protocol:USB Video Class(UVC)
 Support OTG Protocol:USB2.0 OTG
 AEC:Support
 AEB:Support
 AGC:Support
 Adjustable parameters:Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, Gain, White balance, Backlight Contrast, Exposure
 Lens Parameter Standard FOV(D)100 Degree , optional 2.1/2.8/3.7/6mm/FOV(D)170 /180 Degree
 Digital audio High quality digital MIC, support single, dual channel
 LED board power connector:Support 2P-2.0mm socket
 Power supply USB BUS POWER 4P-2.0mm socket
 Power supply:DC5V
 Operating Voltage:140mA~190mA
 Working current -10~70℃
 Working temperature:-20~85℃
 Board size /Weight:38X38mm(Compatible 32X32mm)/ about 30g
 Cable Standard:1M / optional 2M,3M,5M
 Operating system request:Win7,Win8,Linux 2.6 or above,Android 4.0 or above
