SinoTrack 4G GPS Tracker for Vehicles, ST-905L Strong Battery Anti-Theft GPS Tracker Waterproof Locator Real-Time Location Device for Car Motorcycle Truck Taxi with No Monthly Fee Tracking System

HOW TO QUICKLY SETTING UP THE TRACKER?

• STEP 1. – Activate Sim

Buy a local SIM card with 4G(LTE) network function and Install the new sim card into your mobile phone and activate the sim card and remove SIM card’s PIN code. Make sure it can make a call, send a text and has an internet connection. Once this is confirmed, insert SIM to your tracker.

• STEP 2. – Turn on the tracker

Charge it about 1 hour first.

The yellow and blue indicator lights will start flashing while it searches for a network and GPS.

Please wait 5 minutes in a good reception area (by a window or outside) for both lights to come on constantly. It will continue to flash yellow if it can not find a network. Move it to another location.

Please note, when the device has a GPS signal it will get a GPS location. If not it will get its location using LBS.

• STEP 3. - Setting APN for the tracker

(1) You need to know your tracker’s SIM card's APN (You can ask your SIM card provider);

(2) Please note the following operations need From another phone number send text messages command to the tracker’s sim card’s phone number to set tracker's APN.

For example:

APN is: everywhere

APN username is: eesecure

APN password is: secure

(1) If your SIM card’s APN without username and password, then send text command(8030000+space+APN) to the tracker, it will reply “SET OK”.

Text command is: 8030000 everywhere

(2) If your APN with username and password:

Then sned text Command(8030000+Space+ APN+space+ APN user+Space+ APN pass) to the tracker : 8030000 everywhere eesecure secure

Please note: Different SIM card has difference APN. Please apply the above formula according to your actual APN to set up your machine

• STEP 4. - Setting GPRS mode

Send text command to the device to set GPRS mode:7100000

Then wait about 30sec, both blue and orange light should stay ON which mean you can now login to sinotrackpro web or app to check if tracker active. (Username is your tracker’s ID number that write on the product, password: 123456)

If you set ok of all, you can track it online. If it online but show China location, then take it to the outside which signal good place to get GPRS signal, when it get signal, will update your location.

If the device is not online, please check device setting, send: RCONF to device,

It will reply the setting you can check in reply:

1. The APN if is correct;

2. The IP and Port if is correct(IP and port are write in the usermanual,you can check if same as reply)

3. The device working model, (GPRS model)
